In-Depth
Automated System Recovery and System Restore in Windows XP
Windows XP has more efficient tools for backup and recovery.
In addition to the recovery tools available in Win2K, Windows XP includes
yet another feature known as Automated System Recovery (ASR). If Safe
Mode Option and Last Known Good aren’t sufficient to do the job, Windows
XP offers a two-part ASR recovery option that replaces ERD in Win2K. This
tool is available from the Backup Program. The way the Backup program
starts in Windows XP is slightly different than with Win2K. You’re forced
to start with a wizard but then are given the option to either use the
simplified version of this utility or select the Advanced Mode. Click
the Advanced Mode when the wizard starts and you’ll see the screen in
Figure 1.
 |
| Figure 1. Backup Utility Advanced Mode is new
to Windows XP. |
Clicking on Automated System Recovery prompts yet another wizard, the
Automated System Recovery Preparation Wizard. It will back up your system
state, system services and configuration information about hard disks,
such as disk signatures and partitions. The wizard will prompt you for
a floppy disk that contains system settings and will be used to restore
your computer to a previous state. With the aid of this floppy disk and
the backup you create (typically on a hard disk), you can recover from
a system crash. See Figure 2 for the option of restoring an ASR backup.
 |
| Figure 2. Restoring via an ASR Backup. |
System Restore is another cool recovery feature available in Windows
XP. The operating system automatically creates restore points, which allow
you to restore your computer’s configuration to a previous state. The
automatic restore points created by the system are known as system checkpoints.
Data and other important information, such as Internet Explorer favorites,
aren’t affected by these checkpoints.
You can also create manual restore points and give them user-friendly
names. For example, if you’re about to make some major changes to your
computer such as installing a service pack, you should create a system
restore point first. If something goes wrong, you can always revert back
to this previous restore point. Figure 3 shows a manual restore point.
 |
| Figure 3. Some applications create their own
installation restore points in Windows XP. In this example, the application
was TechNet. |
But wait, there’s more! There are additional types of automatic restore
points created by applications. These are known as installation restore
points. For example, each time you update to the latest version of Microsoft
TechNet, Windows XP automatically creates an installation restore point.
As Figure 4 shows, there was an installation restore point created automatically
when the January edition of TechNet was removed from my computer and another
one when the February edition was installed.
 |
| Figure 4. Decreasing the amount of disk space
reserved for System Restore under XP will limit the number of restore
points you can create. |
As you can imagine, creating too many restore points will require a lot
of disk space. Fortunately, there are a couple of options that allow you
to control disk space usage. You can either turn off System Restore completely
or use the slider shown in Figure D to increase or decrease the amount
of disk space reserved for System Restore. To access System Restore, go
to Start | Help and Support Center | Undo changes to your computer with
System Restore, located under the section heading “Pick a task.”
